Description
Tests all types of installations such as heating, compressed air and refrigeration systems, oil installations, fire lines and small bore pipelines. The automatic pressure holding valves enables the user to easily pressurize the system. Compatible fluids include water, oil and ethylene glycol. Can be connected to water supply for rapid filling.
Features
- 3 plunger ceramic piston pump for slow pressure build up and longer life.
- Quick coupling system to disconnect control block and gauge. This can be left on circuit being tested. Pump can be used to pressurize another circuit with second accessory control block.
- Stainless steel container (non acid liquids)
- Water flow: 9 1/min
- Oil (SAE 30)
Specifications
| Continer | Stainless Steel (non acis liquids) |
| Oil | SAE30 |
| Water Flow | 9l/Min |
| Maximum Achievable Test Pressure | 60Bar (with 60 bear control block (not supplied) |
| Maximum Test Pressure as Supplied | 25Bar |
